Copper-clad conductor
Aluminum conductor in 50 mm². Weight: 0.167 kg/m.
Source: Terra product catalog, page 42Download datasheet
Technical specifications
| Product code | TES 20202 |
|---|---|
| Material | Aluminum |
| Copper coating | Yes |
| Type | Mono |
| Conductor size | 50 mm² |
| Weight | 0.167 kg/m |
Conductor and equipment applications
CCA - CCS Conductor
Copper-clad aluminium and copper-clad steel conductors are considered for routes specifying these materials. Select core material and cross-section for the electrical and mechanical requirements of the route.
Applications
Used for earthing panels and machine enclosures, equipotential bonding and site networks. Clamps join conductors; lugs terminate cables at bolted points.
Technical support and documents
Share the installation location and connection you need so our technical team can help select products, dimensions and mounting options. Include drawing and document requests with your quote.
Choose products for your project
- Choose conductor cross-section for the design and connectors for the cable, tape or mono dimensions.
- Consider the environment when selecting material and coating for buried and outdoor connections.
