TERRA / Earthing Sockets
Earthing Terminal
Material: Stainless steel. Height: 200 mm. Weight: 0,29 kg.
Source: Terra product catalog, page 68Download datasheet
Technical specifications
- Product code
- TES 36533
- Material
- Stainless steel
- Steel grade
- 304
- Height
- 200 mm
- Weight
- 0,29 kg
- Stud diameter
- Ø 10 mm
- Lug hole diameter
- Ø 10 mm
Applications
Used to provide an accessible connection between a concrete structure and its earthing network. Choose terminal length and connecting hardware for the foundation and bonding detail.
Technical support and documents
Share the installation location and connection you need so our technical team can help select products, dimensions and mounting options. Include drawing and document requests with your quote.
Documents and product information
Document information comes from the product catalogue. Request the relevant document for your project approval file.
- Stud diameter: Ø 10 mm.
Choose products for your project
Technical options: Material · Height · Weight · Steel grade · Stud diameter · Lug hole diameter.
- Choose terminal length and connection form for concrete thickness, installation detail and the conductor.
- Match hole diameter, screw size and connection count with the lugs and hardware.
Catalogue sources: 68
