Equipotential Bar Flat Type
Equipotential Bar Flat Type. Material: Copper / Steel. Compare material, self support, number of holes options in the product code table below.
Source: Terra product catalog, page 53View product specifications
Product codes and technical options
Click a product code in the table to open its product page and download the datasheet for that code.
| Product code | Material | Self support | Number of holes | Dimensions | Weight | Additional properties |
|---|---|---|---|---|---|---|
| TES 24313 ↗ | Copper | Yok - Not Available | 5 | 30 x 5 x 200 mm | 0,25 kg | — |
| TES 24325 ↗ | Copper | Yok - Not Available | 12 | 30 x 3 x 500 mm | 0,37 kg | — |
| TES 24327 ↗ | Copper | Yok - Not Available | 12 | 30 x 5 x 500 mm | 0,62 kg | — |
| TES 24340 ↗ | Copper | Yok - Not Available | 12 | 40 x 5 x 500 mm | 0,83 kg | — |
| TES 24413 ↗ | Steel | Yok - Not Available | 5 | 30 x 5 x 200 mm | 0,22 kg | Zinc coating: Yes |
| TES 24425 ↗ | Steel | Yok - Not Available | 8 | 30 x 5 x 300 mm | 0,34 kg | Zinc coating: Yes |
| TES 24427 ↗ | Steel | Yok - Not Available | 12 | 30 x 5 x 500 mm | 0,55 kg | Zinc coating: Yes |
| TES 24430 ↗ | Steel | Yok - Not Available | 8 | 40 x 4 x 300 mm | 0,39 kg | Zinc coating: Yes |
| TES 23613 ↗ | Copper | Var - Available | 12 | 25 x 3 x 500 mm | 0,48 kg | — |
| TES 23621 ↗ | Copper | Var - Available | 8 | 30 x 3 x 300 mm | 0,40 kg | — |
| TES 23623 ↗ | Copper | Var - Available | 12 | 30 x 3 x 500 mm | 0,57 kg | — |
| TES 23627 ↗ | Copper | Var - Available | 8 | 30 x 5 x 300 mm | 0,68 kg | — |
| TES 23643 ↗ | Copper | Var - Available | 12 | 40 x 5 x 500 mm | 1,25 kg | — |
| TES 23657 ↗ | Copper | Var - Available | 12 | 50 x 5 x 500 mm | 1,58 kg | — |
| TES 23671 ↗ | Copper | Var - Available | 12 | 60 x 5 x 500 mm | 1,90 kg | — |
Applications
Used at main earthing points, in panel rooms and for industrial bonding. Bringing conductors to one point makes inspection and maintenance access easier.
Technical support and documents
Share the installation location and connection you need so our technical team can help select products, dimensions and mounting options. Include drawing and document requests with your quote.
Choose products for your project
Technical options: Material · Self support · Number of holes · Dimensions · Weight · Zinc coating.
- Set the connection count to cover existing conductors and planned additions.
- Choose bar size, connection holes and supports to suit the lugs and available space.
